Product Overview
12V SMD 2835 LED strip with up to 240 LEDs/m and 9 color options. Flexible 5m strip, IP21/IP65/IP67 available, cuttable and dimmable for indoor and outdoor lighting.
Specification
LED Type: 2835 SMD
LED Quantity : 2835--1200LEDs/5m, 2835--600LEDs/5m, 2835-300LEDs/5m
Color: Warm White / Cold White/Natural White/red/green/blue/pink/ice blue/RGB
Working Input Voltage: DC12V
Lumen: 24-26LM/LED
Protection grade:
IP21: Non-waterproof (Adhesive tape on the back)
IP65: Resin Waterproof (Adhesive tape on the back)
IP67: Tube Waterproof (No adhesive tape on the back)
PCB Color: White
Panel width: 8-10mm
Is Dimmable: Yes(dimmer switch required,but not included)
Is Trimmable: Yes(cuttable every three LEDs)
Drive Mode: Contant Voltage
Beam Angle:120
Viewing Angle: adjustable by mounting position
Working Tempreture:-20 to 50
Package included
1 x 5m led strip lights (power supply is not included)
Features
1. Super bright 2835 SMD top LED, high intensity and reliability.
2. Continuous length, packed with 5 meter.
3. Long life span 60,000+ hours
4. Flexible ribbon for curving around bends
5. Low power consumption
6. Completely smooth and even light spread, solving the uneven luminous problem
7. Ultra-bright but running at low temperature
* Double-panel design, effectively extending the life of LED Strip
*It re-soldered by each 0.5m
Extra Data:
2835 60LEDs/M:
PCB width 8mm,
3-4W/m, 6-8Lm/LED,
color temperature: warm white 2700-3500K, cold white 6000-6500K,
powered by "12V 3A 36W" power supply
2835 120LEDs/M:
PCB width 8mm,
6-8W/m, 8-9Lm/LED,
color temperature: warm white 2700-3500K, cold white 6000-6500K,
powered by "12V 5A 60W" power supply
2835 240LEDs/M:
PCB About 10mm,
10-12W/m, 12-14Lm/LED,
Color temperature: Warm white 2700-3500K, cold white 7500-9000K,
powered by "12V 5A 60W" power supply
